CM/D Series Oxygen Compressor

As one of the oxygen compressors manufacturers, suppliers, and exporters of mechanical products, We offer oxygen compressors and many other products.

Please get in touch with us for details.

Mail:[email protected]

Manufacturer supplier exporter of oxygen compressor

CM/D Series Oxygen Compressor

An oxygen compressor is a device that uses mechanical energy to compress air and remove nitrogen from it. The gas produced is mainly oxygen, with a small amount of nitrogen. Oxygen compressors are commonly used in medical and industrial applications where oxygen is required for a variety of purposes such as welding, medical procedures and manufacturing.

CM/D Series Oxygen Compressor Parameters:

Fixed Speed Series

Model	Work pressure	FAD		Power	Air Supply temperature	Noise	Weight	Pipe diameters of cooling water inlet and outlet	Cooling fan Power	Dimension	Air outlet
	Work pressure	FAD		Power	Air Supply temperature	Noise	Weight		Water entering32℃	L×W×H
	MPa	M³/min	cfm	kW	℃	dB(A)	kg		T/h	mm
CM45D	0.12～0.25	13.80	487	45	≤45	70	1720	1 1/2ʺ	12	2200×1350×1530	DN65
CM55D	0.25～0.40	13.60	480	55		70	1750	1 1/2ʺ	18
CM75D	0.25~ 0. 40	20.1	710	75		72	2300	2 1/2″	20
CM132D	0.12～0.25	43.00	1518	132		78	4380	3ʺ	30	3100×1700×2090	DN125
CM160D	0.25～0.40	42.88	1514	160		78	4500	3ʺ	35	3100×1700×2090	DN125

VSD Series

Model	Work pressure	FAD		Power	Air Supply temperature	Noise	Weight	Pipe diameters of Cooling water inlet and outlet	Cooling fan Power	Dimension	Air outlet
	Work pressure	FAD		Power	Air Supply temperature	Noise	Weight		Water entering 32℃	L×W×H
	MPa	M³/min	cfm	kW	℃	dB(A)	kg		T/h	mm
CM45DV	0.12~0.25	5.50~13.80	194-487	45	≤45	70	1720	1 1/2ʺ	12	2200×1350×1530	DN65
CM55DV	0.25~0.40	5.40~13.60	191-480	55		70	1750	1 1/2ʺ	18
CM75DV	0.25~0.40	8.04~20.1	282-710	75		72	2300	2 1/2″	20
CM132DV	0.12~0.25	17.20~43.00	607-1518	132		78	4380	3ʺ	30	3100×1700×2090	DN125
CM160DV	0.25~0.40	17.10~42.88	604-1514	160		78	4500	3ʺ	35	3100×1700×2090	DN125

CM/D Series Oxygen Compressor Feature:

Energy Saving: Energy saving more than 15% compared with dry oil-free compressors.

Environmental protection: do not use any lubricating oil to avoid environmental pollution.

Reliability: No oil is guaranteed.

We are one of the best food compressor suppliers. We have exported our products to clients around the world and earned a good reputation because of our superior product quality and after-sales service. We warmly welcome customers both at home and abroad to contact us to negotiate business, exchange information, and cooperate with us!
